Jinluo Hose Polyurethane Fracturing Water Supply Hose – High-Performance Oilfield Water Transfer Hose Customized

HOME / PRODUCTS / Oil &Gas Layflat Hose / Jinluo Hose Polyurethane Fracturing Water Supply Hose – High-Performance Oilfield Water Transfer Hose
Jinluo Hose Polyurethane Fracturing Water Supply Hose – High-Performance Oilfield Water Transfer Hose
  • Jinluo Hose Polyurethane Fracturing Water Supply Hose – High-Performance Oilfield Water Transfer Hose
  • Jinluo Hose Polyurethane Fracturing Water Supply Hose – High-Performance Oilfield Water Transfer Hose
  • Jinluo Hose Polyurethane Fracturing Water Supply Hose – High-Performance Oilfield Water Transfer Hose

Jinluo Hose Polyurethane Fracturing Water Supply Hose – High-Performance Oilfield Water Transfer Hose

Cover and Lining: TPU (Extrusion through-the-weave)
Reinforcement layer: Polyester fiber or aramid woven layer
Application: Temporary oil supply of ships, docks, warehouses, field army mechanical units, and oil transportation and drainage in high flammable risk areas such as petroleum and coal mines.
Features: Abrasion resistant, oil resistant, anti-stastic, UV, Ozone and weathering resistant, fungus resistant, kink resistant.
Color: Black, Red, Blue, others on request
Temperature range: -40℃ to 70℃ (-40℉ to 158℉)
Available length: 30m (100ft) - 200m (660ft), others on request
Delivery time: 15-60days
Product origin: China

Product details

Jinluo polyurethane fracturing water supply hose is expertly engineered for the toughest oilfield applications, providing efficient water transfer under high-pressure conditions. Crafted from premium polyurethane, this hose offers outstanding abrasion resistance, exceptional flexibility, and superior durability—making it the ideal choice for hydraulic fracturing operations. Built to withstand the harsh demands of oilfield environments, it guarantees reliable water supply and optimal performance throughout the fracturing process. Designed for heavy-duty water transfer, this hose delivers unmatched strength and longevity, ensuring prolonged service life and consistent reliability in demanding oil and gas operations.

Structure parameters

Norminal Size

Working pressure

Bursting pressure

Weight

Wall Thickness

Inch

mm

PSI/bar

PSI/bar

Lbs./ft  kg/m

Inch  mm

8

204+3.0/-0.0

250/16

700/48

2.2/3.3

0.16/4.2

300/21

900/63

3.02/4.5

0.2/5.1

10

254+3.0/-0.0

150/10

450/30

2.1/3.2

0.18/4.6

250/16

700/48

2.9/4.4

0.19/5.0

12

305+3.0/-0.0

150/10

450/30

3.0/4.5

0.16/4.2

180/13

560/39

3.2/4.8

0.17/4.3

14

358+3.0/-0.0

90/6

260/18

2.7/4.0

0.09/2.5

16

406+3.0/-0.0

150/10

450/30

4.7/7

0.2/5.2

Note: Parameters such as inner diameter, wall thickness, weight, pressure and color can be customized according to customer requirements.
**All above technical parameters are for reference, details please confirm with JINLUO NEW MATERIAL.

Who are we?

Jiangsu Jinluo New Material Technology Co., Ltd. is dedicated to the production and sales of polyurethane layflat fracturing hoses,Oil and Gas Hose、 fire truck remote water supply hoses, industrial hoses, forestry hoses, irrigation hoses, agricultural drag hoses, drinking water delivery hoses, andt renchless pipeline rehabilitation hoses. We are Wholesale Jinluo Hose Polyurethane Fracturing Water Supply Hose – High-Performance Oilfield Water Transfer Hose Suppliers and Customized Jinluo Hose Polyurethane Fracturing Water Supply Hose – High-Performance Oilfield Water Transfer Hose Manufacturers, Our factory is located in Jiangsu, China, and our products are widely used in oil and gas exploration, temporary oil transfer, mineral exploration, agricultural fertilization and irrigation, industrial fluid transfer, trenchless pipeline rehabilitation, emergency response, and construction. Our hoses in caliber from 2 inches to 16 inches, with customizable lengths. Customized calibers and models are available on demand.
