Cover and Lining: TPU (Extrusion through-the-weave)
Reinforcement layer: Polyester fiber or aramid woven layer
Application: Towed tpus, agricultural irrigation, Agricultural slurry transportation
Features: Long life and maintenance-free service in the harshest environment, Excellent resistance to abrasion, puncture and delamination, chemical resistance
Color: Black, Red, Blue, others on request
Temperature range:- 40℃ to 70℃ (-40℉ to 158℉)
Available length: 30m (100ft) - 200m (660ft), others on request
Delivery time: 15-60 days
Product origin: China
Exceptional Adhesion Strength & Superior Fatigue Resistance:
• The TPU liner offers outstanding chemical resistance, ensuring long-term durability.
• The TPU cover provides superior abrasion resistance, even in the harshest conditions.
• Exceptional diameter stability ensures consistent performance over time.
• Capable of transferring larger liquid volumes efficiently.
• Lightweight and flexible, allowing for easy and convenient deployment.
|
ID |
Working pressure |
Bursting pressure |
Weight |
Wall Thickness |
|
|
Inch |
mm |
PSI/bar |
PSI/bar |
Lbs./ft kg/m |
Inch mm |
|
4" |
103+2.0 |
250/16 |
700/48 |
0.77/1.15 |
0.13/3.3 |
|
5" |
128+2.5 |
400/28 |
1200/84 |
1.51/2.25 |
0.18/4.6 |
|
6" |
153+2.5 |
250/16 |
700/48 |
1.43/2.14 |
0.13/3.4 |
|
8" |
205+3.0 |
250/18 |
783/54 |
2.21/3.3 |
0.17/4.2 |
Note: Parameters such as inner diameter, wall thickness, weight, pressure and color can be customized according to customer requirements.
**All above technical parameters are for reference, details please confirm with JINLUO NEW MATERIAL.
Jiangsu Jinluo New Material Technology Co., Ltd. is dedicated to the production and sales of polyurethane layflat fracturing hoses,Oil and Gas Hose、 fire truck remote water supply hoses, industrial hoses, forestry hoses, irrigation hoses, agricultural drag hoses, drinking water delivery hoses, andt renchless pipeline rehabilitation hoses. We are Wholesale Jinluo Hose Polyurethane Irrigation Hose – Flexible, Chemical-Resistant Agricultural Spray, Transfer, Suction, And Discharge Hose for Farming Suppliers and Customized Jinluo Hose Polyurethane Irrigation Hose – Flexible, Chemical-Resistant Agricultural Spray, Transfer, Suction, And Discharge Hose for Farming Manufacturers, Our factory is located in Jiangsu, China, and our products are widely used in oil and gas exploration, temporary oil transfer, mineral exploration, agricultural fertilization and irrigation, industrial fluid transfer, trenchless pipeline rehabilitation, emergency response, and construction. Our hoses in caliber from 2 inches to 16 inches, with customizable lengths. Customized calibers and models are available on demand.
